Shadow plus mod. 9spd sram shifter and drivetrain. 1/4"washer with slot for cable cut down to .236"
Photo 3 of 3
Parts - Drivetrain
Jan 23, 2013 at 7:22
Jan 23, 2013
Kensington, Maryland, United States
Normal – 800 x 600
150 x 113
250 x 188
500 x 375
800 x 600
1024 x 768
1600 x 1200
3264 x 2448
Apple iPhone 5
(Feb 21, 2013 at 6:06)
@Grelax - Its close without mods, but depending on how you set the tension on the cable either the top or bottom end is off. Its marginally acceptable without any changes, but the whole drivetrain will wear faster and the mesh will be off at either end of the cassette. Thats what I have seen anyway. I haven't tried any 8spd shifters yet. I can imagine the outside width of an eight speed chain might be an issue with the 10spd derailleur?
(Jun 18, 2013 at 6:41)
That is AWESOME. Ima get one for sure. BTW- I grew up in Ktown, MD!
(Jul 18, 2013 at 1:33)
I made a ally block to fit like yours, 6mm thick and with a small groove for the cable.
The gears shift great all the way down, great up from the middle to large cogs but not quite there on the lower cogs.
Would a slightly larger block cure the issue?
I did try it without the block and it wasn't good at all
I've just run the setup with the ally block at the Mega Avalanche and it was amazing! so good to ride a quite bike and not to have the sound of a brass band following you down the hill
(Jan 26, 2013 at 7:28)
Sram x9 nine speed. Currently only 10speed clutch derailleurs available. Otherwise I don't see the point. Further reading here...
(Mar 17, 2013 at 10:12)
how have you been getting on with this? any problems? i am considering doing this as i would like a clutch on my bike to try and quiet it down a bit but want to keep 9 speed! also are you running a 9 speed chain?
(May 7, 2013 at 14:08)
@reebs - The washer is .25 thick (height) with a slot filed down to .236 thick. None of the measurements relate to the width. You do however want the slot to be in line with the stock slot of the derailleur.
(May 18, 2013 at 7:36)
Just tried the mod and it works! Did a 15 mile ride and my bike shifted perfect! My setup: Sram X9 shifter pod and a Shimano XT Shadow plus rear derailleur. I used a 6mm spacer.
(Jan 28, 2013 at 11:04)
Roughly six months on the XTR shadow plus in the other pic. Zero issues. Ran this Zee this weekend. Flawless.
(May 5, 2013 at 4:15)
Is the washer 1/4" thick or .236" thick? Which measurement relates to the width and which to the height? Sick mod!
(Jun 11, 2013 at 7:24)
The washer is .25 thick ans the groove filed down where the cable goes is .236 thick.
(Nov 15, 2013 at 8:37)
So SRAM 9 speed cassette/chain/chainwheel and zee rear mech all jive?....or do u need shimano cassette & chain?
(Jan 28, 2013 at 7:27)
dude. AWESOME. how long have you been running this setup?? Any issues after initial cable stretch and break in?
(Feb 17, 2013 at 21:23)
Shouldn't 10sp shimano work with 8/9sp sram shifters without mods?
(Jan 23, 2013 at 10:15)
great idea, and very clean looking. nice job.
(Jan 26, 2013 at 6:31)
What shifter are you running to this? Would a 9speed x9 work?
(May 17, 2013 at 0:43)
Sram shifters will never work with Shimano rear derailleurs.
(May 18, 2013 at 0:47)
Using a 10 speed shimano rear derailleur works with a nine speed sram shifter because the ratios are nearly identical.
(May 22, 2013 at 12:43)
Yeah, im actually know about it now, but this is sucks...Looks cheaper than Saint, but u have to buy the whole 10 speed system. Then which is more expensive? Shimano politics...
(May 22, 2013 at 13:32)
no you don't need the whole 10 speed system. i have installed my zee to day and im running 9 speed everything (chain cassette, chain ring shifter) apart from the zee mech. works well.
(Feb 2, 2013 at 5:42)
