Release Date | 2009 | |
---|---|---|
Price | $4,400 | |
Travel | 150mm | |
Rear Shock | Fox RP23 XV Air Can, custom "all-mountain tuned" w/3-position Pro Pedal, rebound; 8.0x2.25" | |
Fork | RockShox Lyrik 2-step w/E2 alloy steerer, 20mm Maxle, 115-160mm | |
Headset | Frustum Cane Creek SE Light Edition; 1 1/8" top, 1.5" bottom | |
Cassette | SRAM PG950 11-32, 9 speed | |
Crankarms | Shimano Deore XT 44/32/22 | |
Rear Derailleur | Shimano Deore XT "Shadow", Front: Shimano Deore XT, high mount | |
Front Derailleur | Shimano Deore XT, high mount | |
Shifter Pods | Shimano Deore XT | |
Handlebar | Bontrager Race, 40mm rise, 31.8mm, 690mm width | |
Stem | Bontrager Race Lite, 7 degree, 31.8mm | |
Brakes | Shimano Deore XT Ti, custom Ti for Trek; 203mm front rotor, 180mm rear rotor | |
Wheelset | Bontrager Rhythm Comp wheel system, 28mm, tubeless ready | |
Tires | Kenda Nevegal w/SWS sidewall protection, 26x2.35"; 127 tpi | |
Seat | Bontrager Rhythm w/hollow Cro-Moly rails | |
Seatpost | Bontrager Race Lite, 5mm offset |
Size | S | M | L | XL |
---|---|---|---|---|
Frame Weight | ||||
Bike Weight | ||||
Headtube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
Seattube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
Headtube Length | ||||
Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm |
BB Height | 350 mm | 350 mm | 350 mm | 350 mm |
BB Width | ||||
Seat Post Diameter | ||||
Front Derailleur Width | ||||
HeadTube Diameter | E2 | E2 | E2 | E2 |
Top Tube Length | 555 mm | 591 mm | 615 mm | 644 mm |
WheelBase | 1095 mm | 1132 mm | 1157 mm | 1188 mm |
Standover Height | 740 mm | 745 mm | 760 mm | 780 mm |
