Release Date | 2009 | |
---|---|---|
Price | $1,600 | |
Rear Shock | Rock Shox BAR 2.1 7.5 x 2, air sprung with rebound damping adjust | |
Fork | SR MAG 32 with 140 mm travel, air sprung with aluminum steerer, magnesium lowers and 7050 upper tubes, rebound damping adjustable | |
Headset | FSA Orbit X 1 1/8" forged cups, sealed bearings | |
Cassette | SRAM PG-950 9-speed, 11-32 | |
Crankarms | FSA Alpha Drive 44/32/22 | |
Bottom Bracket | FSA sealed cartridge | |
Pedals | Shimano PDM -520 | |
Rear Derailleur | Shimano Deore | |
Chain | Shimano Nine Speed | |
Front Derailleur | Shimano Deore | |
Shifter Pods | Shimano Deore 9-speed | |
Handlebar | GT 31.8mm Riser | |
Stem | GT over size four bolt | |
Grips | GT Lock Down, co molded locking grip system | |
Brakes | Tektro Auriga Pro Hydraulic, forged two piston caliper with mineral oil | |
Hubs | Shimano 6 bolt Disc | |
Spokes | DT Swiss 1.8 stainless steel | |
Rim | WTB SX -24, 32 hole, black anodized, for presta valve. | |
Tires | Front: 26"x 2.3 Kenda Nevgal, 120 tpi with Kevlar bead, Rear: same only 2.1 | |
Seat | WTB Pure V | |
Seatpost | GT alloy |
Size | XS | S | M | L | XL |
---|---|---|---|---|---|
Frame Weight | |||||
Bike Weight | |||||
Headtube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
Seattube Angle | 72.9 ° | 72.9 ° | 72.9 ° | 72.9 ° | 72.8 ° |
Headtube Length | 100.07 mm | 100.07 mm | 109.98 mm | 130.04 mm | 150.11 mm |
Chainstay Length | 430.78 mm | 430.78 mm | 430.78 mm | 430.78 mm | 430.78 mm |
BB Height | 346.96 mm | 346.96 mm | 346.96 mm | 346.96 mm | 346.96 mm |
BB Width | |||||
Seat Post Diameter | |||||
Front Derailleur Width | |||||
HeadTube Diameter | 1.125 | 1.125 | 1.125 | 1.125 | 1.125 |
Top Tube Length | 549.91 mm | 564.89 mm | 584.96 mm | 599.94 mm | 629.92 mm |
WheelBase | 1070.10 mm | 1085.08 mm | 1105.91 mm | 1121.91 mm | 1152.90 mm |
Standover Height | 700.02 mm | 702.56 mm | 718.31 mm | 732.28 mm | 752.85 mm |
About Us
Contacts FAQ Terms of Use Privacy Policy Sign Up! SitemapAdvertise
AdvertisingCool Features
Submit a Story Product Photos Videos Privacy RequestRSS
Pinkbike RSS Pinkbike Twitter Pinkbike Facebook Pinkbike Youtube Pinkbike Instagram
Pros-Good Components, lightweight, control, price
Cons-26 inch wheels (which some people actually might like)
