Price | $3,050 | |
---|---|---|
Travel | 130mm | |
Rear Shock | Fox FLOAT R shock | |
Fork | Fox 32 Talas R, air spring, external rebound adjustor, 15mm thru-axle, 100 - 120 - 140mm adjustable travel | |
Headset | Ritchey Pro Logic Press fit, semi-integrated with 20mm shim stack, 1 1/8” | |
Cassette | Sram PowerGlide 950 , 9-speed, 11-34 | |
Crankarms | FSA V-Drive MegaExo, 44/32/22, 170mm (13-15”), 175mm (17-21”) | |
Bottom Bracket | FSA MegaExo integrated | |
Pedals | Crank Brothers Acid clipless | |
Rear Derailleur | Shimano Deore XT Shadow rear | |
Chain | Sram PowerChain 971 with Gold Power-Link | |
Front Derailleur | Deore XT 34.9mm top pull front | |
Shifter Pods | Shimano Deore XT Rapidfire Plus-SL, 27-speed | |
Handlebar | Ritchey Mountain Pro Rizer, 31.8mm x 20mm x 660mm wide | |
Stem | Ritchey Pro 4-Axis, 31.8 O˚ x 6˚ rise x 90mm(13-15”), 100mm (17-19”), 120mm (21”) | |
Grips | WTB MotoTec clamp-on, DNA compound | |
Brakes | Hayes Stroker Trail, hydraulic disc brakes with V7 front & V6 rear rotors | |
Wheelset | Mavic XM317 eyeletted disc rims, 32H, Shimano XT front disc hub w/ 15mm thru-axle, XT rear disc hub, WTB 14g stainless steel spokes | |
Tires | Kenda Nevegal, 26 x 2.35”, Stick-E compound | |
Seat | WTB Rocket V Comp with SL cover | |
Seatpost | Ritchey Pro 2B OS, 31.6 x 350mm, with alloy clamp & cromo seatpin |
Size | 13" | 15" | 17" | 19" | 21" |
---|---|---|---|---|---|
Frame Weight | |||||
Bike Weight | 30.20 lbs | 30.20 lbs | 30.20 lbs | 30.20 lbs | 30.20 lbs |
Headtube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
Seattube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
Headtube Length | 115 mm | 115 mm | 120 mm | 140 mm | 150 mm |
Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
BB Height | 327 mm | 327 mm | 327 mm | 327 mm | 327 mm |
BB Width | |||||
Seat Post Diameter | 31.6 " | 31.6 " | 31.6 " | 31.6 " | 31.6 " |
Front Derailleur Width | 34.9 mm | 34.9 mm | 34.9 mm | 34.9 mm | 34.9 mm |
HeadTube Diameter | 1.125 | 1.125 | 1.125 | 1.125 | 1.125 |
Top Tube Length | 539 mm | 562 mm | 579 mm | 602 mm | 612 mm |
WheelBase | 1059 mm | 1077 mm | 1094 mm | 1118 mm | 1123 mm |
Standover Height | 711 mm | 728 mm | 752 mm | 785 mm | 812 mm |
