Price | $985 | |
---|---|---|
Fork | SR Duro Dirt Jump, coil spring/hydraulic damping, magnesium sliders, 100mm travel | |
Headset | Aheadset, external cups, 20mm shim stack, 1 1/8” | |
Cassette | Relic 9:1 cog spacer with 14T cog | |
Crankarms | 4130 Chromoly crank, 28t chainring, 175mm | |
Bottom Bracket | 4130 Chromo spindle for 3-pc crankset | |
Pedals | Crank Bros 5050 platforms | |
Chain | KMC Z410 | |
Handlebar | Syncros FR38 6061, 31.8 O˚ x 9/4˚ sweep x 38mm rise x 710mm | |
Stem | Syncros FR50, 3D forged 6061, 31.8 bar bore x 15˚ rise x 50mm | |
Grips | Alienation Mr. Hand with 14mm end caps | |
Brakes | Hayes Stroker Ryde hydraulic disc brakes, V6 front & V5.5 rear rotors | |
Wheelset | Alienation Black Sheep rims, 6mm pins, 32H, Formula alloy disc hubs, sealed bearing rear, WTB 14g stainless steel spokes | |
Tires | Kenda K-Rad, 26 x 2.3” | |
Seat | Alienation Recliner, SL cover, corduroy strip, ABR corners | |
Seatpost | Alienation Billy Club Pivotal, 25.4 x 242mm |
Size | 14" | 15" |
---|---|---|
Frame Weight | ||
Bike Weight | 32.20 lbs | 32.20 lbs |
Headtube Angle | 69.5 ° | 69.5 ° |
Seattube Angle | 72 ° | 72 ° |
Headtube Length | 115 mm | 115 mm |
Chainstay Length | 400 mm | 400 mm |
BB Height | 320 mm | 320 mm |
BB Width | ||
Seat Post Diameter | 25.4 " | 25.4 " |
Front Derailleur Width | ||
HeadTube Diameter | 1.125 | 1.125 |
Top Tube Length | 557 mm | 594 mm |
WheelBase | 1017 mm | 1054 mm |
Standover Height | 748 mm | 760 mm |
