Price | $1,975 | |
---|---|---|
Travel | 100mm | |
Rear Shock | Fox Float R | |
Fork | Rock Shox Domain 302 U-Turn, 35mm stanchions, external rebound damping adjustor, Maxle 20mm axle, 115-160mm travel | |
Headset | Zero-Stack internal cup, threadless, 20mm shim stack, 1 1/8” | |
Cassette | SRAM Powerglide 950, 9-speed, 11-32 | |
Crankarms | FSA Step Up, 32/22T heat-treated cromo chainrings, 170mm | |
Chainguide | e-13 SuperCharger bash guard | |
Bottom Bracket | FSA ISIS, sealed cartridge, 73 x 118mm | |
Pedals | Flatbed alloy platform with pedal spikes | |
Chain | KMC Z9000 | |
Rear Derailleur | Shimano Deore XT Shadow rear, mid-cage | |
Front Derailleur | Shimano SLX front, 34.9mm top pull | |
Shifter Pods | Shimano Deore Rapidfire-SL, 27-speed | |
Handlebar | Syncros AM 20 riser, double-butted 6061, 31.8 O˚ x 9/4˚ sweep x 20mm rise x 670mm | |
Stem | Syncros FR 50, 3D forged 6061, 31.8 bar bore x 15˚ rise X 50mm | |
Grips | WTB Weirwolf, dual DNA compound | |
Brakes | Hayes Stroker Ryde Hydraulic disc brakes, V8 front & V7 rear rotors | |
Wheelset | WTB Dual Duty FR eyeletted rims, Formula 20mm thru-axle front & Shimano M475 rear disc hubs, WTB 14g stainless steel spokes | |
Tires | Kenda Nevegal, 26 x 2.3” | |
Seat | WTB Pure V with black diamond cover & corners | |
Seatpost | Syncros Derived 2-piece OS, 31.6 x 350mm with alloy QR clamp |
Size | 15.5" | 17" | 18" |
---|---|---|---|
Frame Weight | |||
Bike Weight | 36.50 lbs | 36.50 lbs | 36.50 lbs |
Headtube Angle | 68 ° | 68 ° | 68 ° |
Seattube Angle | 73 ° | 73 ° | 73 ° |
Headtube Length | 120 mm | 120 mm | 120 mm |
Chainstay Length | 428 mm | 428 mm | 428 mm |
BB Height | 332 mm | 332 mm | 332 mm |
BB Width | 73 mm | 73 mm | 73 mm |
Seat Post Diameter | 31.6 " | 31.6 " | 31.6 " |
Front Derailleur Width | 34.9 mm | 34.9 mm | 34.9 mm |
HeadTube Diameter | 1.125 | 1.125 | 1.125 |
Top Tube Length | 534 mm | 561 mm | 605 mm |
WheelBase | 1057 mm | 1085 mm | 1129 mm |
Standover Height | 756 mm | 758 mm | 758 mm |
