Price | $1,199 | |
---|---|---|
Fork | Marzocchi Dirt Jumper 2 100mm | |
Headset | FSA ZST-10 | |
Cassette | Shimano HG40 (11-32, 8spd) | |
Crankarms | FSA Moto-X | |
Chainguide | E.Thirteen STS | |
Bottom Bracket | FSA MegaExo | |
Pedals | Kona Jackshit Primo | |
Chain | Shimano HG50 | |
Rear Derailleur | Shimano Alivio | |
Shifter Pods | Shimano Acera | |
Handlebar | Kona Cowan Signature | |
Stem | Kona Clump | |
Grips | Cowan Lock-On Signature | |
Brakes | Shimano M575 Hydraulic Disc | |
Hubs | Front - Formula DH, Rear - Shimano M525 Disc | |
Spokes | Sandvik Stainless14g | |
Rim | Sun EQ 3.1SL | |
Tires | Maxxis Holy Roller 26x2.2 | |
Seat | Alienation Recliner/Pivotal | |
Seatpost | Alienation Billy Club/Pivotal |
Size | 12 | 14 | 15 |
---|---|---|---|
Frame Weight | |||
Bike Weight | 31.1 lbs | 31.1 lbs | 31.1 lbs |
Headtube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
Seattube Angle | 71 ° | 71 ° | 71 ° |
Headtube Length | 110 mm | 115 mm | 120 mm |
Chainstay Length | 397 mm | 411 mm | 411 mm |
BB Height | 324 mm | 329 mm | 329 mm |
BB Width | 73 mm | 73 mm | 73 mm |
Seat Post Diameter | |||
Front Derailleur Width | 34.9 mm | 34.9 mm | 34.9 mm |
HeadTube Diameter | 1.125 | 1.125 | 1.125 |
Top Tube Length | 551 mm | 569 mm | 594 mm |
WheelBase | 1021 mm | 1055 mm | 1080 mm |
Standover Height | 732 mm | 748 mm | 761 mm |
