| Price | $1,499 | |
|---|---|---|
| Travel | 5" | |
| Rear Shock | RockShox Bar 2.1 | |
| Fork | RockShox Dart 2 w/Turnkey 120mm | |
| Headset | TH | |
| Cassette | Shimano Deore (11-32, 9spd) | |
| Crankarms | FSA Alpha Drive | |
| Bottom Bracket | FSA Powerdrive | |
| Pedals | Shimano M505 Clipless | |
| Rear Derailleur | Shimano LX | |
| Chain | KMC HG53 | |
| Front Derailleur | Shimano Deore | |
| Shifter Pods | Shimano Deore | |
| Handlebar | Kona XC/BC Riser | |
| Stem | Kona XC/BC | |
| Grips | Kona Race Light | |
| Brakes | Shimano M486 Hydraulic Disc | |
| Hubs | Front - Formula Disc, Rear - Shimano M475 Disc | |
| Spokes | Sandvik Stainless 15g | |
| Rim | Alex ACE-18 | |
| Tires | Maxxis Ignitor 26x2.1 | |
| Seat | WTB Rocket V Comp | |
| Seatpost | Kona XC/BC |
| Size | 14.4 | 16 | 17 | 18 | 19 | 20 | 22 |
|---|---|---|---|---|---|---|---|
| Frame Weight | |||||||
| Bike Weight | 31.7 lbs | 31.7 lbs | 31.7 lbs | 31.7 lbs | 31.7 lbs | 31.7 lbs | 31.7 lbs |
| Headtube Angle | 69.8 ° | 69.8 ° | 69.8 ° | 69.8 ° | 69.8 ° | 69.8 ° | 69.8 ° |
| Seattube Angle | 74.3 ° | 74.3 ° | 74.3 ° | 74.3 ° | 74.3 ° | 74.3 ° | 74.3 ° |
| Headtube Length | 125 mm | 125 mm | 125 mm | 130 mm | 130 mm | 150 mm | 150 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| BB Height | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm |
| BB Width | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Seat Post Diameter | |||||||
| Front Derailleur Width | 31.8 mm | 31.8 mm | 31.8 mm | 31.8 mm | 31.8 mm | 31.8 mm | 31.8 mm |
| HeadTube Diameter | 1.125 | 1.125 | 1.125 | 1.125 | 1.125 | 1.125 | 1.125 |
| Top Tube Length | 544 mm | 557 mm | 570 mm | 583 mm | 596 mm | 607 mm | 620 mm |
| WheelBase | 1068 mm | 1080 mm | 1095 mm | 1108 mm | 1121 mm | 1133 mm | 1146 mm |
| Standover Height | 750 mm | 757 mm | 771 mm | 785 mm | 798 mm | 820 mm | 845 mm |
About Us
Contacts FAQ Terms of Use Privacy Policy Sign Up! SitemapAdvertise
AdvertisingCool Features
Submit a Story Product Photos Videos Privacy RequestRSS
Pinkbike RSS Pinkbike Twitter Pinkbike Facebook Pinkbike Youtube Pinkbike Instagram
Great XC/Trail bike. I have upgraded wheels, brakes, handle bars and stem (Mavic Crossmax SLR wheels, 70mm Thomson stem, 720mm Race Face bar and XT brakes) and have gone to 1x9 (32 tooth). It is light and fast and handles all that I have thrown at it, from rocky rooty descents to 5 ft drops. Climbs well, makes tight switchbacks easy. It has a bit steep of a Head Tube Angle of 69.5, which took me a bit to get used to coming from a slacker ride (Kona Coiler) It is not a plush over the roots and rocks as the Coiler was, but so much lighter and faster on tight twisty XC trails and climbs. It can easily handle more than the typical XC bike, but it is not a 6" AM bike either, somewhere in between. Current weight is about 28.5 lbs. This is the 19" Frame. I am 6' 1" and weight 178. I have had it for 4 years, and ride at least once a week on very rooty XC singletrack
