Release Date | 2009 | |
---|---|---|
Price | $3,500 | |
Travel | 165mm | |
Rear Shock | Marzocchi ROCO Air R, 5 position compression, bottom out resistance, oversize air can, and rebound adjust, 216x63 mm w/ 19x8 mm hardware | |
Fork | Marzocchi 55 ATA Micro 125-165 travel adjust, micro compression adjust, nickel stanchions, air spring with progressive bottom out, 20 mm QR thru axle | |
Cassette | SRAM PG-950 Cassette11-34T | |
Crankarms | Shimano SLX 22/36T/BASH Hollow Tech II | |
Bottom Bracket | Shimano external bearing | |
Pedals | Crank Bros. Acid | |
Rear Derailleur | Shimano XT, Shadow mount, Front: Shimano SLX for 22/36T Combo | |
Chain | Shimano HG73 | |
Front Derailleur | Shimano SLX for 22/36T combo | |
Shifter Pods | Shimano SLX 18 speed | |
Handlebar | Gravity Light, triple butted and shot peened AL7050, 31.8x 25x710 mm | |
Stem | Gravity Light, 31.8x50 mm | |
Grips | Mongoose Lock on | |
Brakes | Hayes Stroker Trail w/ tool free reach adjust | |
Hubs | Formula sealed bearing cassette, 15mm Front. | |
Spokes | DT Competition double butted with alloy nipples | |
Rim | No Tubes ZTR Flow 32 hole | |
Seat | SDG Bel Air RL cromoly rail | |
Seatpost | Cobra R adjustable height w/ remote 31.6 x 350 mm |
Size | S | M | L |
---|---|---|---|
Frame Weight | |||
Bike Weight | 33.2 lbs | 33.2 lbs | 33.2 lbs |
Headtube Angle | 67 ° | 67 ° | 67 ° |
Seattube Angle | 71.5 ° | 71.5 ° | 71.5 ° |
Headtube Length | 119.38 mm | 129.54 mm | 139.7 mm |
Chainstay Length | 434.34 mm | 434.34 mm | 434.34 mm |
BB Height | 347.98 mm | 347.98 mm | 347.98 mm |
BB Width | |||
Seat Post Diameter | |||
Front Derailleur Width | |||
HeadTube Diameter | 1.125 | 1.125 | 1.125 |
Top Tube Length | 568.96 mm | 594.36 mm | 619.76 mm |
WheelBase | 1104.9 mm | 1130.3 mm | 1155.7 mm |
Standover Height | 728.98 mm | 754.38 mm | 789.94 mm |
