Price | $2,799 | |
---|---|---|
Travel | 150mm | |
Rear Shock | Fox DHX 3.0 Coil | |
Fork | Domain 318 ut 1.5 | |
Headset | Cane Creek Double X or Chris King Upgrade | |
Cassette | SRAM PG 970, 11/32 | |
Crankarms | TruVativ Hussefelt 24/36 w/ bash guard | |
Bottom Bracket | TruVativ Howitzer Team | |
Chain | SRAM PC 971 | |
Rear Derailleur | SRAM X9 medium cage | |
Front Derailleur | Shimano M805 (Saint) | |
Shifter Pods | SRAM X7 triggers | |
Handlebar | TruVativ Hussefelt 31.8mm | |
Stem | Race Face Evolve DH, 31.8mm | |
Grips | Lizard Skin Charger | |
Brakes | Avid Elixir R w/ 203mm front rotor, 185mm rear rotor | |
Wheelset | Mavic EX 325 rims laced to DT 340 hubs w/ DT 14 guage spokes, brass nipples | |
Tires | Kenda Nevegal 2.5 wire | |
Seat | WTB Pure V Race FR | |
Seatpost | Race Face Evolve DH |
Size | SM | M | L |
---|---|---|---|
Frame Weight | |||
Bike Weight | |||
Headtube Angle | 67.5 ° | 67.5 ° | 67.5 ° |
Seattube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
Headtube Length | 104.14 mm | 114.3 mm | 129.54 mm |
Chainstay Length | 431.8 mm | 431.8 mm | 431.8 mm |
BB Height | 363.22 mm | 363.22 mm | 363.22 mm |
BB Width | |||
Seat Post Diameter | 30.9 " | 30.9 " | 30.9 " |
Front Derailleur Width | |||
HeadTube Diameter | 1.5 | 1.5 | 1.5 |
Top Tube Length | 546.1 mm | 579.12 mm | 609.6 mm |
WheelBase | 1 064.26 mm | 1 097.28 mm | 1 130.3 mm |
Standover Height | 749.3 mm | 754.38 mm | 784.86 mm |
