Release Date | 2009 | |
---|---|---|
Price | $3,000 | |
Travel | 210mm | |
Rear Shock | Marzocchi ROCO R rebound and preload adjust, 241x76 mm w/ 19x8 mm hardware | |
Fork | Marzocchi 888 RCV 200 mm travel, rebound, compression and preload adjust, 20 mm thru axle | |
Cassette | SRAM PG-950 Cassette 11-26 | |
Crankarms | Truvativ Hussefelt with cromoly pedal inserts1.0 36T ring | |
Chainguide | E.13 LG1 ISCG05 chainguide w/ Taco bash guard | |
Bottom Bracket | Truvativ Howitzer TM (83 mm shell) | |
Pedals | Mongoose Alloy platform with replaceable pins | |
Chain | Shimano HG73 | |
Rear Derailleur | Shimano Saint Shadow with SS cage | |
Shifter Pods | Shimano SLX 9 speed | |
Handlebar | Funn Full Bore triple butted AL7075 riser, 25.4x50x710 mm | |
Stem | FUNN MZ2 25.4x45 mm direct attach for Marzocchi, CNC alloy | |
Grips | Mongoose Lock on | |
Brakes | Hayes Stroker Trail w/ tool free reach adjust | |
Hubs | Sealed bearing 150x12 thru axle casstte, 20mm Front. | |
Spokes | DT Champion 14G stainless | |
Rim | SUN MTX-31 32 hole | |
Tires | Kenda Excavator DH w/ Stick-E rubber 26X2.5 | |
Seat | Custom Mongoose SDG Bel Air I-Beam | |
Seatpost | SDG I-Beam 6061 alloy, 31.6x250 |
Size | S | M | L |
---|---|---|---|
Frame Weight | |||
Bike Weight | 42.8 lbs | 42.8 lbs | 42.8 lbs |
Headtube Angle | 65.5 ° | 65.5 ° | 65.5 ° |
Seattube Angle | 66 ° | 66 ° | 66 ° |
Headtube Length | 120 mm | 120 mm | 120 mm |
Chainstay Length | 445 mm | 445 mm | 445 mm |
BB Height | 352 mm | 352 mm | 352 mm |
BB Width | |||
Seat Post Diameter | |||
Front Derailleur Width | |||
HeadTube Diameter | 1.125 | 1.125 | 1.125 |
Top Tube Length | 590 mm | 615 mm | 635 mm |
WheelBase | 1095 mm | 1120 mm | 1140 mm |
Standover Height | 768 mm | 764 mm | 762 mm |
