| Release Date | 2009 | |
|---|---|---|
| Price | $6,050 | |
| Travel | 203mm | |
| Rear Shock | Fox DHX 5 Coil, custom "gravity tuned" w/external rebound, 15-click Pro Pedal, boost valve; 8.75x2.75" | |
| Fork | RockShox Totem Coil w/E2 alloy steerer, rebound, high/low speed compression, Mission Control, 180mm | |
| Headset | Custom Cane Creek E2; 1 1/8" top, 1.5" bottom | |
| Cassette | SRAM PG970 11-32, 9 speed | |
| Crankarms | Shimano "New" Saint, 83mm bottom bracket, 36T | |
| Chainguide | MRP System 3 Chainguide w/Party Crasher bash guard | |
| Pedals | Bontrager Big Earl platform | |
| Rear Derailleur | Shimano "New" Saint "Shadow" SS | |
| Shifter Pods | Shimano "New" Saint, Rapidfire Plus | |
| Handlebar | Bontrager Earl, 50mm rise, 31.8mm | |
| Stem | Bontrager Big Earl, 10 degree, 31.8mm | |
| Brakes | Shimano "New"Saint w/Servo Wave; 203mm front rotor, 180mm rear rotor | |
| Wheelset | Bontrager Big Earl wheel system, 20mm front, 12mm rear w/150mm spacing | |
| Tires | Bontrager Big Earl w/Stability Control Casing, 26x2.5"; 60 tpi | |
| Seat | Bontrager Big Earl | |
| Seatpost | Bontrager Big Earl |
| Size | S | M | L | XL |
|---|---|---|---|---|
| Frame Weight | ||||
| Bike Weight | ||||
| Headtube Angle | 65° | 65° | 65° | 65° |
| Seattube Angle | 58° | 58° | 58° | 58° |
| Headtube Length | ||||
| Chainstay Length | 440mm | 440mm | 440mm | 440mm |
| BB Height | 363mm | 363mm | 363mm | 363mm |
| BB Width | ||||
| Seat Post Diameter | ||||
| Front Derailleur Width | ||||
| HeadTube Diameter | E2 | E2 | E2 | E2 |
| Top Tube Length | 573mm | 596mm | 622mm | 622mm |
| WheelBase | 1145mm | 1168mm | 1193mm | 1193mm |
| Standover Height | 830mm | 830mm | 830mm | 830mm |
