$4500 USD
Roughly 600 miles on this playful machine. Bone stock still
The Mondraker DUNE R E-Mountain Bike is what happens when a heavy-hitting e-bike goes on a diet. The lightweight Bosch Performance Line SX motor keeps things nimble and natural-feeling on climbs, while 165mm of travel and Mondraker's signature long, slack Forward Geometry mean it's totally at home charging steep, technical descents. A mullet wheel setup adds front-end stability without killing the playfulness, and the Bosch app unlocks even more performance when you're ready to dive in
Specs
Frame Stealth Air full Carbon, Updated Zero Suspension System, Mullet, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
Fork FOX 38 Float 3P Performance Grip, 170mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
Rear Shock Fox Float X Performance EVOL, 205x65mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings
Rims e*thirteen Grappler Core, Hookless 6066 Welded Aluminum 30mm internal width, tubeless ready, 28F spokes 29 front, 27''''''''5 rear
Hubs Front: e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts
Rear: e*thirteen Boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, HG Freehub
Spokes e*thirteen custom J-bend, triple-butted steel, alloy nipples, nipple washers
Tires Front: Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
Rear: Maxxis Minion DHR II 27’5x2.4 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 2x120TPI, folding bead
Crankset e*Thirteen Helix Core E*Spec Plus, All sizes: 160mm
Chainrings SRAM X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Shifters SRAM Trigger NX Eagle, 12s, X-Actuation 1:1, single click
Rear Derailleur SRAM GX Eagle,12s
Cassette/Freewheel SRAM PG-1230, 11-50T, 12s
Chain SRAM NX Eagle, 12s, Powerlock
Brakes SRAM DB8 stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brake Levers SRAM DB8, SwingLink and lever pivot bearings, tools-free reach and contact point adjust
Handlebars Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.
Tape/Grips Onoff Forest, CNC lock-on, 135mm
Stem Onoff S6 30mm 0º, 6061 forged alloy + CNC, 31.8mm barbore
Headset Acros custom IS52/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock
Seatpost Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), L size: 180-155mm (468-275mm), XL size: 210-185mm (528-305mm)
Saddle Fizik Terra Aidon Slim X5
Pedals Sold Separately
Motor Bosch Performance Line SX (20 Mph) GEN4 SMART SYSTEM Diagonal, Wide
Battery Bosch Compact Powertube 400Wh
Controller/Display Purion 400 / Bosch Mini Remote / Bosch System Controller
