| Price | $2,800 | |
|---|---|---|
| Travel | 152mm | |
| Rear Shock | Specialized AFR Shock w/ Spike valve, air spring, adj. rebound and low speed compression, 7.875x2.25" | |
| Fork | Fox 32 Float RL, 1-1/8" steerer, 15mm thru-axle, 150mm travel w/ compression and rebound adj. | |
| Headset | 1-1/8" Threadless, 10mm insertion alloy cups, sealed cartridge bearing | |
| Cassette | Shimano HG61, 9-speed, 11-34t | |
| Crankarms | Custom Shimano FC-M542, S: 170mm, others: 175mm | |
| Bottom Bracket | Shimano FC-M542 | |
| Rear Derailleur | SRAM X-9, 9-speed, mid cage | |
| Chain | SRAM PC-971, 9-speed w/Power Link | |
| Front Derailleur | Shimano M660 SLX, DMD, top swing, dual pull | |
| Shifter Pods | SRAM X-7, aluminum trigger, 9-speed | |
| Handlebar | Specialized Enduro mid rise bar, 6066 alloy, 31.8mm, 6 degree up, 9 degree backsweep, 660mm wide | |
| Stem | Specialized adjustable rise, 31.8mm clamp, 3D forged w/ CNC finish | |
| Grips | Specialized thin lock on grip (S/M) Specialized Thick lock on grip (L/XL) | |
| Brakes | Custom Avid Elixir R SL, alloy backed organic pads | |
| Hubs | Specialized Hi-Lo disc, 15mm thru-axle, 32h. Rear: Custom Shimano M525 SL, alloy QR, 32h | |
| Spokes | DT Swiss 1.8mm stainless, black, alloy nipples | |
| Rim | Custom DT Swiss E440S, 26mm, sleeved w/eyelets, 32h | |
| Tires | S-Works Eskar, 26x2.3", 120 TPI, aramid tubeless ready bead, dual compound | |
| Seat | Specialized Format, hollow Cr-Mo rails, SL foam, S/M/L: 130mm XL:143mm | |
| Seatpost | 2014 butted alloy, single bolt setback, 30.9x350/400mm |
| Size | S | M | L | XL |
|---|---|---|---|---|
| Frame Weight | ||||
| Bike Weight | 30.2lbs | 30.2lbs | 30.2lbs | 30.2lbs |
| Headtube Angle | 67° | 67° | 67° | 67° |
| Seattube Angle | 71.9° | 71.9° | 71.9° | 71.9° |
| Headtube Length | 102mm | 108mm | 128mm | 150mm |
| Chainstay Length | 421mm | 421mm | 421mm | 421mm |
| BB Height | 356mm | 356mm | 356mm | 356mm |
| BB Width | ||||
| Seat Post Diameter | 30.9" | 30.9" | 30.9" | 30.9" |
| Front Derailleur Width | ||||
| HeadTube Diameter | 1.125 | 1.125 | 1.125 | 1.125 |
| Top Tube Length | 545mm | 574mm | 602mm | 630mm |
| WheelBase | 1115mm | 1147mm | 1177mm | 1205mm |
| Standover Height | 742mm | 748mm | 762mm | 782mm |
