Price | $7,078 | |
---|---|---|
Travel | 254mm | |
Rear Shock | Fox DHX 5.0 Coil. | |
Fork | RockShox Boxxer World Cup | |
Headset | Chris King | |
Cassette | SRAM PG 970, 11-26 | |
Crankarms | TruVativ Holzfeller OCT 38 tooth | |
Chainguide | Gamut chainguide included | |
Bottom Bracket | TruVativ Howitzer Team | |
Chain | SRAM PC 991 | |
Rear Derailleur | SRAM X0 short cage | |
Shifter Pods | SRAM X0 right trigger | |
Handlebar | Easton Havoc low riser (31.8) | |
Stem | Sun Line Boxxer direct mount | |
Grips | Lizard Skin Peaty lock on | |
Brakes | Avid Elixir CR w/203mm rotors (f) and 185mm (r) | |
Wheelset | DT FR 6.1D rims laced to DT 440 hubs w/ DT 14 guage spokes, brass nipples | |
Tires | Kenda Nevegal 2.5 front 2.3 rear wire | |
Seat | WTB Rocket V Stealth | |
Seatpost | Thompson |
Size | SM | M | L |
---|---|---|---|
Frame Weight | |||
Bike Weight | |||
Headtube Angle | 67 ° | 67 ° | 67 ° |
Seattube Angle | 71 ° | 71 ° | 71 ° |
Headtube Length | 111.76 mm | 119.38 mm | 127 mm |
Chainstay Length | 441.96 mm | 441.96 mm | 441.96 mm |
BB Height | 375.92 mm | 375.92 mm | 375.92 mm |
BB Width | |||
Seat Post Diameter | 30.9 " | 30.9 " | 30.9 " |
Front Derailleur Width | |||
HeadTube Diameter | 1.125 | 1.125 | 1.125 |
Top Tube Length | 556.26 mm | 589.28 mm | 629.92 mm |
WheelBase | 1 102.36 mm | 1 137.92 mm | 1 176.02 mm |
Standover Height | 746.76 mm | 751.84 mm | 767.08 mm |
